78 Chapter 7 Reference Welch Allyn Vital Signs Monitor 300 Series Recommended separation distances between portable and mobile RF communications equipment and the Vital Signs Monitor 300 Series monitor The Vital Signs Monitor 300 Series monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
2
English
Welch Allyn Spot Vital Signs
5.
Press the Mode (
) button once to save the change. Repeat steps 4 and 5 to set
the day, month, year, hour, and minute values.
6.
Press the Power (
) button to exit the Internal Configuration Mode.
Configuration Menu Options
Setting
Description
Blood Pressure Calibration
Displays “Cal”
Prepares the Spot Vital Signs for calibration. Only qualified personnel should verify the
Spot Vital Signs blood pressure calibration.
Inflation Pressure Preset Level
Displays “PrP”
120, 140, 160, 180, 200, 240, 280 mmHg. Factory default is 160 mmHg.
Pressure Preset Level
Displays “PrP“
On or off. Disables or enables the front panel Pressure Preset button.
Backlight
Displays “BLT”
On or off.
Welch Allyn Vital Signs Monitor 52000 Series Manual
Mean Arterial Pressure
Displays “MAP”
On or off.
Date/Time
Changes or updates the actual date and time.
Temperature Scale
Displays “TMP MOD”
Fahrenheit (°F) or Celsius (°C) Normal Mode / Fahrenheit (°F) or Celsius (°C) Monitor
Mode
Blood Pressure Units
Displays “BP”
mmHg or kPa.
Battery Readings
Displays “BAT”
Displays the total battery voltage.
Battery Life
Displays “LFE”
Total number unit measurements. Displayed information only; operator cannot change.
1
English
Set the date and time
After recharging a dead battery or after disconnecting the battery for a few minutes, you
must program the date and time screen.
You can change several device operating parameters in the Internal Configuration Mode.
When changed, these settings become the default power-up settings. You will also see
non-changeable device configurations for technical service purposes.
To enter the Internal Configuration Mode:
1.
Welch Allyn Spot Vital Signs Manual
Turn the Spot Vital Signs off (
).
2.
Press and hold the Blood Pressure Start/Stop (
) and Power (
) buttons. The
device enters the Internal Configuration Mode and displays the software version.
If the device displays E38, press the Next Patient/Clear/Cancel (
) button to
cancel the error.
3.
Press the Mode (
) button to cycle through the Internal Configuration menu until
you see the date option displayed on the screen.
4.
Use the Next Patient/Clear/Cancel (
) or Blood Pressure Start/Stop (
)
buttons to change the default setting.
