52
20
51. Remove the M10 Nylon Locknut (75) used in step
47.
Wrap the Long Cable (62) over a 90mm Pulley
(38). Attach the Pulley and a Cable Trap (37) to
the Right Seat Frame (3) with the M10 x 119mm
Bolt (76) used in step 47 and the M10 Nylon
Locknut (75). Make sure that the Cable Trap is
turned to hold the Cable in place.
53. Remove the M10 Nylon Locknut (75) used in step
45.
Gold's Gym Xr 55 Manual
Wrap the Long Cable (62) under a 90mm Pulley
(38). Attach the Pulley and a Cable Trap (37) to
the Right Upright (5) with the M10 x 110mm Bolt
(88) used in step 45, an M10 Washer (74), and
the M10 Nylon Locknut (75). Make sure that the
Cable Trap is turned to hold the Cable in
place.
54. Wrap the Long Cable (62) over a 90mm Pulley
(38). Attach the Pulley and a Cable Trap (37) to
the second set of holes from the bottom of the
Double “U”-bracket (41) with an M10 x 48mm Bolt
(23) and an M10 Nylon Locknut (75). Make sure
the Cable Trap is turned to hold the Cable in
the groove of the Pulley.
55. Wrap the Long Cable (62) under a 90mm Pulley
(78). Attach the Pulley and a Cable Trap (37) to
the Right Base (1) with an M10 x 48mm Bolt (23)
and an M10 Nylon Locknut (75). Make sure that
the Cable Trap is turned to hold the Cable in
place.
52. Remove the M10 Nylon Locknut (75) used in step
46.
Wrap the Long Cable (62) over a 90mm Pulley
(38). Attach the Pulley and a Cable Trap (37) to
the Press Frame (14) with the M10 x 119mm Bolt
(76) used in step 46, and the M10 Nylon Locknut
(75). Make sure that the Cable Trap is turned
to hold the Cable in place.
51
53
54
Gold's Gym Xr 45 System
55
75
37
62
3
38
76
75
37
62
38
14
75
74
37
38
88
5
62
23
41
38
37
62
76
Gold's Gym Xr 45 User Manual Free
75
23
37
62
38
75
1
