Universal

Thermostats

•Auto-Changeover

•7 Day, 5/1/1 Day Programmable or Non-Programmable

•Hardwired or Battery Powered

1F85-277

Multi-Stage/Heat Pump/Single Stage

7 Day, 5/1/1 Day Programmable or Non-Programmable

1F85-275

Multi-Stage/Heat Pump/Single Stage

5/1/1 Day Programmable or Non-Programmable

1F83-277

Multi-Stage/Heat Pump/Single Stage

Non-Programmable

ACCURACY

Programmable Non-Programmable

Creating the World of Universal Thermostats for

Single Stage, Multi-Stage, Heat Pump and Truck Stock Use.

We’ve improved the best-selling digital thermostat by combining a single stage, multi-stage and heat pump into one universal thermostat. And better yet we’ve enhanced it with the new styling and home comfort features, specially designed for all systems. It now offers more control, more convenience and more value than the competition. And it’s backed with the reputation of White-Rodgers — pioneers in home comfort since 1937.

More Accuracy and Control. If you’re in the process of upgrading a multi-stage, heat pump or single stage system, don’t forget the “brain” for your new system…your thermostat. Our White-Rodgers 80 Series can maintain a set temperature to within one degree. Plus, there’s a permanent memory that saves all programs and settings during a power loss.

Comfort and Convenience with Versatility.

The programmable models deliver perfect comfort, as they automatically change to the temperature you selected for wake-up, during the day, evening hours and while you sleep. You can also configure them with minimum and maximum temperature range for cooling or heating. The new 40% larger lighted display makes for clearer low-light viewing.

Maximum Energy Savings. Program heating and cooling times to cut energy use, not comfort. You can save up to 33% in energy costs, depending on your home’s location, climate and program selections.

Now you can have it all…energy savings, with comfort and convenience! See the back to find out how this best-seller gives you more of what you want in a universal thermostat.

White Rodgers 1f85 275

1F83-277

Multi-Stage/Heat Pump/Single Stage

Non-Programmable

Dimensions

6.1'H x 3.8'W x 1.1'D

Electrical Specifications

Rating

20 to 30 VAC, 50/60 Hz or DC

0.05 to 1.0 Amp (load per terminal)

2.5 Amps maximum load (all terminals combined)

Standard Systems

Multi-Stage—2 stage heat, 2 stage cool Heat Pump—2 or 3 stage heat, 1 stage cool Single stage gas, oil, electric

Thermal Specifications

Setpoint Temperature Range: 45° to 90°F (7° to 32°C)

Rated Differential:

0.6° to 1.6°F with adjustable anticipation

Operating Ambient Temperature: 32° to 105°F (0° to 40°C)

Operating Humidity Range: 90% non-condensing maximum

White Rodgers 1f85-275 Manual

Shipping Temperature Range: -4° to 150°F (-20° to 65°C)

Accessories

Wall Plate F61-2500 (7.6'W x 4.8'H)

Thermostat Guard F29-0231

(For additional guard options refer to White-Rodgers catalog)

For Additional Information

Visit www.white-rodgers.com
